Specifications

Nominal system voltage – 12 / 24 VDC Auto

Rated charge current – 20A

Rated discharge current – 20A

Battery input voltage range – 8 – 32V

Max. PV open circuit voltage – 50V

Self – consumption – 12V <-5mA , 24V <-7mA

USB output port – 5VDC / 1.2A

Working environment temp. – -35C – +55C degrees

Humidity – <-95% N.C

Dimensions 148 x 86 x 35mm

Mounting hole size diameter 4.5

Terminals – 12AWG / mm2

Net weight – 0.18kg
